M6 Teleskoper Blank Changer milling unit

With the new M6 Teleskoper Blank Changer milling unit, Zirkonzahn automates processes, accelerates procedures and increases the productivity of the dental workflow.

The five plus one axis simultaneous milling unit is equipped with a magazine for 16 or 56 blanks (upgradeable up to 150-200). It also features a Blank Changer that allows material blanks to be transferred autonomously from the magazine to the orbit.

Once the new structure is completed, the blanks are reinserted again in their correct place in the magazine. This means that restorations made of different dental materials, colours and heights can now be designed fully automatically. No manual intermediate steps are needed.

The wet and dry processing function permits the milling of all common soft and hard dental materials. The built-in Teleskoper Orbit M6 allows the processing of material blanks with a diameter of 95mm, 98mm, 106mm and 125mm.

Thanks to special holders, also glass-ceramic blanks, Raw-Abutment blanks and zirconia blanks (size 1) can be milled. In addition, the innovative Teleskoper functions (adjustment of the friction, Double Milling, Stop & Go) can be used with the M6 milling unit.

‘Optimally adapted’ milling

Zirkonzahn equips the M6 milling unit with the new Performance Spindle M6 by default. Thanks to a specially developed Permanent Magnet Synchronous Motor (PMSM) which is optimally adapted to the milling unit, this spindle can reach a maximum torque of 200ncm at speeds of 6.000 to 50.000rpm with a peak power of 2.5kW.

In addition, the milling unit is equipped with a contamination-protected tool chamber. This is separate from the milling chamber and features an automatic 60-compartment tool changer function.

Up to two magazines with 30 slots each can be stored in a safely and orderly manner. This allows for up to 60 milling tools.

The tools are automatically checked for type or damage before and after each milling process.
